Ultra-High Detail Reproduction

Automatic Calibration and Mesh Bed

Compensation

Integrated Curated Online Model Library

Supports High Hardness, Impact-Resistant,

Deformation-Resistant Filaments

Reliable and Flexible Structure

Triple Protection Against Microparticle Threats

Time-Lapse Photography

and Selective Part Skipping

Larger Print Size:

300*300*300 mm
Materials Unlocked, Creativity Unbounded
Equip your various imaginations with ideal materials.
PEEK
PC
PEI
PA
PPS

PEEK (Polyetheretherketone) is a lightweight, high-performance polymer that is distinguishing itself in the field of lightweight and durable component manufacturing due to its exceptional mechanical properties, thermal stability, and chemical compatibility.

PC(Polycarbonate), also known as “bulletproof plastic,” exhibits exceptional impact resistance and good heat resistance. It is frequently utilized in products like face shields, automobile lighting, and model airplanes.

PEI(Polyetherimide) offers excellent mechanical, thermal, and electrical properties and is widely used in fields such as semiconductors, electronic devices, and communication equipment applications.

PA(Polyamide) is a well-balanced and versatile engineering polymer. As a true all-rounder, it is an ideal choice for replacing metal or rubber components in a variety of applications.

PPS(Polyphenylene Sulfide) fiber-reinforced is a polymer with multiple high resistances, making it an excellent material for protective gear, cover plates, or surface-mounted components.

Perfectly Print Functional Filaments That Truly Match Your creative Vision
Powered by a control system with excellent handling of nearly all filaments forming conditions (melting and curing).
Stably outputs Strong and Durable Masterpieces
Alcheman uses configuration parameters derived from thousands of hours of testing by expertsand and users across various vertical fields, masterfully handling a wide range of materials.
Each Layer Precisely Combined, Achieving Exceptional Surface Quality.
Generates Stronger Layer Adhesion, Enhancing the Mechanical Properties of the Finished Product.
Avoids Common Warping and Eliminates Frustrating Failures.
Stand out with Alcheman
  • PEEK
  • PPS
  • PEI
  • ABS
  • PA
  • PC
Automatically Achieves Beautiful Printing on the First Layer
The thermal expansion of the build plate often results in slight but print quality-impacting deformation, which Alcheman accurately detects and Algorithmically compensates for dynamically.
Automatic Calibration, Hands-Free Operation
The intelligent electromagnetic induction sensor automates Z-axis Tilt Calibration with micron-level precision, ensuring absolute accuracy and reliability for every operation.
Maximizing Your 3D Printing Creativity
Our powerful algorithms, developed and tested over time, enable Alcheman to perfectly reproduce complex details.
Applying fluid dynamics and flow calibration algorithms, it proactively compensates for material
flow rates in response to motion inertia.

Equipped with a vibration input shaping algorithm that

automatically and precisely calibrates the resonance

frequencies of the X and Y axes, ensuring every detail

of the print job is faithfully reproduced.

Consistent and Fast Every Time
A multi-tested and optimized all-metal body effectively resists flexing, enhancing multi-print consistency, model accuracy, and longevity. Lightweight and robust carbon fiber components reduce inertia and deformation, boosting print efficiency and accuracy.
Your Health, Our Priority
A professional-grade filter with triple protection of ULPA, Melt-blown nonwoven fabric and activated carbonis integrated in Alcheman. With the encloseddesign, there is no need to worry about harmful fumesor strong odors.
Independently tested remove up to
93%
of different particles from every print.
Tested by Cti-cert, Only including Elyarchi materials*
Expand Your Creative Horizons
High-specification designed operator interface integrates a cloud-based model library, enabling a seamless transition from concept to reality, all at your fingertips.
Toward the “Big Time”
More room to maneuver, easy printing without disassembling, and more robust all-in-one large models.
The 7-inch screen provides a richer browsing experience.
Uninterrupted Production, Eternal Creativity
View or intervene in the progress of your work in real-time on the software and create vlogs with time-lapse photography.
Document the Entire Process of Your Creative Growth with Time-Lapse Photography.
Product Specifications
Components Type Parameter
Body Build Volume 300x300x300mm
Chassis Steel
Shell Aviation Aluminum Alloy
Tool Head Hot End Ceramic
Extruder Gears Metal & Nylon
Nozzle Brass
Max Hot End Temperature 300℃
Nozzle Diameter (Included) 0.4mm
Hot Bed Build Plate Flexible Steel Plate
Supported Filament General Purpose: PLA, ABS, PETG, PC, Nylon, TPU
Engineering & Industrial Grade: PEEK, PPS, PEI, PA, PC
Speed Max Speed of Tool Head 500mm/s
Max Acceleration of Tool Head 20000 mm/s²
Max Hot End Flow -
Cavity Temperature Control Active Chamber Temperature Control √
Maximum Controllable Chamber Temperature 450℃
Air Purification Particulate Matter Filtration √
Sensors Pressure Sensor √
Cooling Part Cooling Fan √
Hot End Fan √
Control Board Fan √
Chamber Temperature Regulator Fan √
Auxiliary Part Cooling Fan √
Air Filter Ultra-low particulate air (ULPA)
Power Requirements Voltage 18V
Maximum Power 350W
Electronic Component Display 7 Inches
Storage 16GB
Wi-Fi Frequency Range 2.4G
Protocol IEEE 802.11 b/g/n
Ethernet Interface RJ45
Speed Gigabit
Physical Dimensions Dimensions 450x450x562 mm
Net Weight -
